Wake.empire Concept prototype · no OpenFOAM data
Drag to pan · use Detail zoom to get closer
First wake · 0–12 ft behind stern
Illustrative three-dimensional boat and wake, with adjustable speed, ballast, weight distribution, surf tabs, hull shape, and heading.
Ballast location Freshwater · calm lake · straight course

Distances assume a 22 ft reference hull. Heights are illustrative inches; vertical shape is exaggerated. 0 ft is the reference stern.

Crest heights · first 12 ftIllustrative inches · uncalibrated · not CFD
Crest elevation profileLive schematic crest elevation behind the stern. These inch values use an assumed display scale and are not measured or predicted physical heights.

Side tabs hinge downward into the water. Travel is illustrative; the center trim tab is not modeled.

Schematic controls · total boat mass not modeled · no fluid-flow calculation
